| Section - A |
| Packaging Materials With Totaly Packaging Solution. |
| |
|
| 1. |
PP Strap (Non Metallic BOX STRAPPING.) |
| |
|
| 2. |
Pet Strap. |
| |
We offer sizes from 11mm to 19mm in width and 0.6mm to 1.2mm in thickness suitable for manual & Automatic Strapping Operation. |
| |
|
| 3. |
BOPP TAPES. |
| |
|
| 4. |
G.I. Clips |
| |
Gripper [serrated] seals for PP, PET strapping. 30mm long.
GP 12 for 12 mm straps.
GP 15 for 15 mm straps. |
 |
|
| 5. |
Sutli |
| |
|
| 6. |
Cord Strap & Woven lashing strap |
| |
|
Cord Strapping is Co-Extruded polyester Strapping.
High tensile Polyester Filament yarn bonded in polymer coating.
Woven Lashing is Manufactured from high tenacity polyester yarn
Application
Woven lashings are widely used to secure cargo in containers & trucks. |
 |
| |
|
|
|
|
|
|
|
|
Composite |
16mm |
850 |
675 |
Composite |
19mm |
600 |
1500 |
Lash |
25mm |
500 |
1500 |
Lash |
32mm |
300 |
2400 |
|
 |
| |
|
|
| |
Heavy duty wire metal bucklet for PET,PP & card strapping.
CWB 5 for 15 mm wide.
CWB 6 for 19 mm wide. |
|
|
| 7. |
Stretch Warp film |
| |
|
Width :75 mm to 500 mm
Thickness : 17 -50 micron |
|
| |
|
| 8. |
LDPE Shrink Wrap and Polyole film |
| |
 |
| 9. |
Edge Protectors or Angle Board |
| |
|
Size : 25 mm X 25 mm to 100 mm X 100 mm
Thickness : 2.5 mm to 6 mm |
|
| |
|
| 10. |
Air Bubble Sheet |
| |
| |
Lightweight, water resistant, transparent sheet with excellent cushioning properties |
|
| |
S.K.Industries group offers Air Bubble wrap sheets, a flexible and transparent plastic sheeting containing numerous small air pockets. The sheets offer cushioning and scratch protection fan superior to packing paper and are used to protect items during shipping and storage. Bubble wrap is lightweight, water resistant, reusable non-scratching and is used for packing fragile items. It can also be used to cushion medium to heavy weight products |
|
| 11. |
EMA Film - Masking Film (Surface Protection film) |
| |
|
| 12. |
Steel Strap. |
| |
|
| 13. |
HM/LD/PP/HDPE Bags and Rolls |
| |
|
| 14. |
Dunnage Bags |
| |
|
|
| |
| Section - B |
| |
| Packaging Machine and Machine Tools. |
| |
|
| 1. |
Semi Automatic Strapping Machines. |
| |
Features : |
 |
| |
» |
Strap at quick speed and with high efficiency only takes 1.5 second for strapping one polypropylene strap. |
|
Instant - heating systems, low voltage of 1V, high safety and will be in best strapping state in 5 second after you start the machine. |
» |
Automatic stopping device, saves electricity and makes it practical. The machine will automatically stop and be in standby state when you don't operate it beyond 60 seconds. |
» |
Electromagnetic clutch and smooth coupled - axle transmission, quick speed, low noise, low wear and tear and low breakdown rate. |
|
|
| |
| Specifications |
|
|
| Power Supply |
: |
220V, AV Single Phase |
| PP Strap width |
: |
6-15 mm |
| Min. strapping |
: |
60 mm |
| Max. Strapping |
: |
No Limit |
| Strapping Speed |
: |
1.5 (Sec./Strap) |
| Volume (L x W x H) |
: |
895 x 565 x 730 |
| Weight of Machine |
: |
100 kgs. |
| Max. Tension |
|
60 kgs. |
|
| |
|
| 2. |
Fully Automatic Strapping Machines. |
| |
| |
 |
| Features : |
» |
Aluminium arch-all in one design. Easy to increase the width or the height, only add some parts to the original. |
|
The guide of the brush is big help to strap the packages at the proper position. Brilliant performance. |
» |
Makes operation easy, time saving, labour saving. |
» |
The advanced P.C.B. Microchip circuit board control system, less malfunction and easy maintenance. |
» |
Tension adjustments : Can be adjustable at will. |
» |
Precision structure : Main machine component is made of Aluminium alloy. |
» |
Easy loading or uploading : To load or unload the strapping roll is convenient due to the dispenser placed outside. |
| |
|
| Specifications |
|
|
| Power Supply |
: |
220V, AV Single Phase |
| PP Strap width |
: |
9, 12, 15, 19 mm |
| Strap Tension |
: |
Max 90 kgs. |
| Strapping Speed |
: |
2.4 (Sec./Strap) |
| Volume (L x W x H) |
: |
1460 x 606 x 1521 |
| Weight of Machine |
: |
250 kgs. |
|
| |
|
|
|
| 3. |
Carton Sealing Machine |
| |
| |
 |
Model No. |
Length
Min |
(mm)
Max
|
Width
Min |
(mm)
Max |
Height
Min |
(mm)
Max |
ST - TB |
150 |
Unlimited |
160 |
450 |
80 |
550 |
ST - BD |
150 |
Unlimited |
160 |
450 |
100 |
350 |
|
|
| |
|
| 4. |
Pet Pneumatic Machine and battery machine. |
| |
|
Battery Powered ZP 22 / ZP 26
Automatic Standard Tension |
|
|
| |
Width 11 - 19 mm X 0.65 - 1.05 mm Thickness
Tool Weight : 4.25 kg.
Tension - 2000 N / 3300 N |
| |
Battery Powered Tool
| Specifications |
|
|
| Strap type |
: |
PP & Pet straps |
| Strap Width |
: |
0 mm (ST-45-09), 12 mm(ST-45-12) or 15.5mm (ST-45-16) |
| Strap Thickness |
: |
0.40mm-1.05mm |
| Max. Strap Tension |
: |
240kgs/2400 N |
| Joint Efficiency |
: |
80-85% |
| Max. Tension Speed |
: |
270mm/second |
| Net Weight |
: |
4.3 Kgs |
|
 |
|
| 5. |
Stretch Straping Machine. |
|
|
| |
| Section - C |
| Master Batches & Filler and Additive Master batch, filler |
|
| |
|
| |
